Research Article  Open Access
Tianbin Wo, Meelis Noemm, Dapeng Hao, Peter Adam Hoeher, "Iterative Processing for Superposition Mapping", Journal of Electrical and Computer Engineering, vol. 2010, Article ID 706464, 13 pages, 2010. https://doi.org/10.1155/2010/706464
Iterative Processing for Superposition Mapping
Abstract
Superposition mapping (SM) is a modulation technique which loads bit tuples onto data symbols simply via linear superposition. Since the resulting data symbols are often Gaussianlike, SM has a good theoretical potential to approach the capacity of Gaussian channels. On the other hand, the symbol constellation is typically nonbijective and its characteristic is very different from that of conventional mapping schemes like QAM or PSK. As a result, its behavior is also quite different from conventional mapping schemes, particularly when applied in the framework of bitinterleaved coded modulation. In this paper, a comprehensive analysis is provided for SM, with particular focus on aspects related to iterative processing.
1. Introduction
According to Shannon's information theory, the capacity of a Gaussian channel corresponds to the maximum mutual information between channel inputs and outputs [1, 2]. Given a power constraint, this maximum can be achieved if and only if the channel inputs are Gaussian distributed. Since Shannon's seminal work in 1948, many approaches have been proposed to map binary bits onto Gaussianlike distributed symbols. Among these approaches, the most wellknown ones are Huffman decoding [3] and signal shaping [4]. By using a Huffman decoder to map bits onto a signal constellation with a welldesigned distribution, for example, the MaxwellBoltzmann distribution [5], one can maximize the mutual information between channel input and output for a given symbol cardinality and average power. Unfortunately, this approach demands variablerate transmission and is consequently undesirable for practical applications. In contrast, signal shaping techniques are fixedrate transmission schemes and for this reason have attracted interest in the field of realworld implementations. There are two popular methods for signal shaping, namely trellis shaping [6] and shell mapping [7, 8]. Both trellis shaping and shell mapping share a common idea, that is to construct a highdimensional uniform constellation which results in lowdimensional nonuniform constituent constellations. They are both able to deliver a shaping gain of about dB [9] without any additional effort with respect to channel coding, but subject to the assumption of noniterative demapping and decoding. In case of iterative softin softout (SISO) demapping and decoding, the blockwise mapping manner inherent in popular shaping techniques presents a bottleneck to the design of receiver algorithms.
To overcome the drawbacks of Huffman decoding and signal shaping, several researchers proposed different transmission schemes employing linear superposition to generate Gaussianlike symbols [10–12]. Without loss of generality, we denote the key component of such techniques as superposition mapping (SM). The characteristic feature of SM is that the conversion from binary bits to data symbols is done by a certain form of superposition instead of bijective (onetoone) mapping. Since the output of a superposition mapper is often Gaussianlike, the necessity of doing active signal shaping is eliminated. On the other hand, superimposed signal components interfere with each other, and the resulting relationship between bit tuples and data symbols is often nonbijective. To guarantee a perfect reconstruction at the receiver side, channel coding and interleaving are typically mandatory, and iterations between the decoder and demapper are essential. This incurs a structure well known as bitinterleaved coded modulation (BICM) [13]. For an easy reference, we may call such a transmission technique bitinterleaved coded modulation with superposition mapping (BICMSM).
In this paper, we provide a comprehensive study on the performance of BICMSM, with particular focus on aspects related to iterative demapping and decoding. Theoretical as well as numerical results are provided. Via mutual information analysis, the capacityachieving potential of superposition mapping is demonstrated. Due to the superimposed signal structure and the nonuniform signal distribution, the requirements of a superposition mapper on the channel code are essentially different from that of a uniform bijective mapper like PSK/QAM. Through EXIT chart analysis, we will show that repetition coding is in fact superior for coded SM systems. In addition to these analytical investigations, two practical issues are also considered. A novel treepruning concept is proposed to reduce the demapping complexity, and a baseband clipping scheme together with an iterative soft compensation mechanism is presented to reduce the signal peaktoaverage power ratio (PAPR), while keeping the system performance degradation at an acceptable level.
The remainder of this paper is organized as follows. Section 2 introduces the Gaussian channel model under investigation. Section 3 provides a brief description of superposition mapping and related information theoretical aspects. Section 4 treats the application of superposition mapping in the framework of bitinterleaved coded modulation. In Section 5, an extensive study is carried out on iterative demapping and decoding process of coded SM systems. Particular focus is put on the convergence behavior of the iterative receiver given different channel codes. In Section 6, several approaches for lowcomplexity demapping are discussed, and in Section 7 a novel method for PAPR control is proposed. Finally, Section 8 summarizes the paper and suggests some interesting topics for future work.
2. Gaussian Channel
The additive white Gaussian noise (AWGN) channel is perhaps the most important channel model with continuous outputs. Though simple, it models the fundamental effects of communication in a noisy environment. The discretetime complex AWGN channel model can be written as where is the time index. The mutual information between the channel input and output is given by where denotes differential entropy. Since the normal distribution maximizes the entropy for a given variance, the maximum of is achieved when is Gaussian distributed. Strictly speaking, can only be Gaussian if is Gaussian. In practice, however, it often suffices if is Gaussianlike, given a reasonable signaltonoise ratio (SNR).
3. Superposition Mapping
Figure 1 shows the general structure of superposition mapping. After serialtoparallel (S/P) conversion, each code bit is first converted into a binary antipodal symbol . (Due to superposition mapping, binary antipodal component symbols bring no limit with respect to the overall bandwidth efficiency.) Then, power allocation and phase allocation are performed. Afterwards, the complex component symbols (called “chips”) are linearly superimposed to create a finitealphabet data symbol. SM can be described by the following equation: where is called the bit load of the superposition mapper. By tuning the amplitudes and the phases , different superposition mapping schemes can be obtained. In case of equal power allocation, that is, when all amplitudes are the same, all bits are equally protected. It was shown in [14] that, given a BICM system with standard coding approaches, direct superposition mapping (DSM) with equal power allocation suffers from limited supportable bandwidth efficiency, and DSM with unequal power allocation suffers from power efficiency degradation. In contrast, phaseshifted superposition mapping (PSM) provides virtually unlimited supportable bandwidth efficiency and desirable power efficiency. For this reason, this paper will exclusively focus on PSM, while most of the analysis can easily be extended to the case of DSM.
3.1. PhaseShifted Superposition Mapping
PSM is characterized by the following power and phase allocation: All chips are allocated with the same magnitude, and each chip is allocated with a unique phase uniformly drawn over the interval . Substituting (4) into (3), we obtain Since , the total energy spent for each bit is constant. Hence, PSM is characterized by a high power efficiency provided by superposition mapping with equal power allocation. On the other hand, from (5) one can see that unequal power allocation is actually done in the real and imaginary dimension, respectively, due to the individual phase shift. This increases the cardinality of the output symbol and greatly enhances the supportable bandwidth efficiency. As a consequence, PSM does not suffer from limited supportable bandwidth efficiency.
Figure 2 illustrates the PSM constellation for different bit loads, and Figure 3 shows the probability distribution of one quadrature component of the PSM outputs. For , the PSM constellation looks like circular 16QAM, while for larger , the constellation points tend to be geometrically Gaussianlike distributed. (The central limit theorem cannot be applied here, since are independent but not identically distributed due to individual phase shifts.) It can be easily proven that the real part and the imaginary part of are statistically independent. Therefore, the constellation points of PSM are approximately circular Gaussian distributed, though in no case perfect.
(a)
(b)
(c)
(a)
(b)
(c)
3.2. An Information Theoretical View
Given the distribution of , the mutual information (MI) can be numerically evaluated. Figure 4 provides MI curves for PSM as well as for square QAM. Comparing Figure 4(a) with Figure 4(b), it can be seen that PSM outperforms QAM in the left region, and it is almost capacity achieving, which is due to the Gaussianlike symbol distribution. The gap between the capacity curve and the slope for highorder QAM in Figure 4(b) corresponds to the ultimate shaping gain [9]. On the other hand, PSM is worse than QAM in the right region, which is due to a smaller minimum distance between distinct constellation points. Last but not least, in most cases, PSM and QAM provide roughly the same entropy per symbol, given an identical bit load , which can be seen by comparing the smooth sections of the MI curves. An important message from the above observations is that, with PSM, signal shaping is no longer necessary to approach the capacity of the Gaussian channel. As a matter of fact, the mutual information given PSM input symbols can be arbitrarily close to the capacity at any SNR, as long as the bit load is large enough.
(a) PSM
(b) QAM
3.3. Rate Limit of PSM
Following (1), the limit of coding rate for PSM transmission over the AWGN channel is given by Hence, the bandwidth efficiency of PSM is virtually unlimited and the required spreading factor () should not be very large. The bandwidth efficiency limit at about bits/symbol per signal dimension reported in [15] is in fact due to the adopted Gaussianapproximationbased demapping algorithm rather than the mapping scheme itself.
4. BitInterleaved Coded Modulation with Superposition Mapping
Bitinterleaved coded modulation [13] is widely recognized as a promising technique to approach the channel capacity at high SNRs. Typically, higherorder QAM is used to achieve a high bandwidth efficiency, while an interleaver is placed between the encoder and the signal mapper to exploit the bit diversity of QAM. With the same structure but replacing QAM with superposition mapping (SM), we obtain the BICMSM transmission scheme under investigation.
4.1. General Structure
Figure 5 shows the transmitter and receiver structure of BICMSM, where SD stands for superposition demapping. Since a superposition mapper is often a nonbijective (manytoone) mapper, iterations between the demapper and the decoder are not only necessary but mandatory. A superposition demapper usually can not work properly without utilizing the redundancy introduced by the channel code. This is quite different in comparison with the demapper of conventional mapping schemes, like a PSK/QAM demapper, which does not necessarily have to cooperate with the channel decoder.
4.2. SoftIn SoftOut Demapping
The superposition demapper needs to provide soft decisions of each code bit given the channel outputs and the a priori information from the decoder. Given an AWGN channel, an APP softinput softoutput (SISO) demapper for SM can be described as follows. Let collect the bits excluding loaded on one symbol, we have where assuming statistical independence of interleaved code bits. The APP demapping algorithm, in spite of its high complexity, is the first choice for theoretical analyses, as it provides the best performance. In the following measurements, APP demapping is applied, if not specifically addressed.
5. Iterative Processing for Superposition Mapping
Due to the geometrically nonuniform symbol distribution, we observe that PSM is better than square QAM in the sense of mutual information over the Gaussian channel. As long as the bit load is large enough, PSM can efficiently fill up the dB gap, well known as the ultimate shaping gain in the terminology of signal shaping, between the channel capacity and the mutual information with uniform signalling. Nevertheless, due to linear superposition with equal power allocation, the behavior of a PSM demapper, in the scenario of iterative demapping and decoding is very different from that of a demapper of conventional mapping schemes like PSK/QAM. This in fact implies some different concepts for the code design. In this section, we will have an indepth study on the iterative demapping and decoding process of coded PSM systems via an EXIT chart analysis [16, 17].
5.1. First Impression on the Performance
To start, let us first have a look at the performance of coded PSM. We consider two type of codes, lowdensity parity check (LDPC) codes, which are known to be capacityachieving for binaryinput Gaussian channels, and repetition codes, considered to be weak codes as they provide no coding gain at all on the AWGN channel. As shown in Figure 6, the true situation is in fact opposite to the common understanding, that is, repetitioncoded PSM can even outperform LDPCcoded PSM, particularly at large bit loads . Another noteworthy phenomenon is that the performance of LDPCcoded PSM degrades severely as the bit load increases. All these observations indicate that the classical purely paritycheckbased channel codes do not really fit with a superposition mapper, which is to be studied in the next sections.
5.2. MI Transfer Characteristics of APP Demapper
To start an analysis on PSM, we will have a look at the mutual information (MI) transfer characteristics of the SISO APP demapper. Square QAM with Gray labeling will be used as reference for comparison.
Let us begin the discussion with the starting points in the left side of Figure 7. Compared to PSM, QAM with Gray labeling has considerably higher starting points, given the same bit load. The starting points show how reliable will be the output of the demapper given only the channel output and no a priori information from the decoder. For PSM with large , the starting points are very low. Hence, the demapper output in the first iteration(s) is very weak. This comes from the fact that the constellation diagram, Figure 2, is densely populated in the central region, which leads to a reduced minimum distance and in some cases even to nonbijective mapping. This effect can be clearly observed in Figure 7(b) for both PSM and QAM, where the starting points improve as the SNR increases.
(a) dB
(b)
The slope of the curves presents the most obvious difference. For QAM with Gray labeling, the curves are more or less horizontal, with modest slopes for . On the other hand, for PSM the curves have steep slopes, excluding . For the curves are even convex. The slope of the curves characterizes the importance or usefulness of iterations. Hence in case of PSM, as the feedback from the decoder becomes more reliable from iteration to iteration, the demapper output improves. On the contrary for QAM, usually only a few iterations are sufficient and the gain by feedback of extrinsic information is noticeably smaller.
At last we come to the ending points of the MI transfer plots. Figure 7(a) presents an interesting fact. In the case of PSM, given the same , for all selections of , the curves end in the same point. This relates to the fact that all code bits are converted to binary antipodal symbols. If the feedback information is very reliable, then we are left with a detection scenario for BPSK transmission over a Gaussian channel. For QAM, the ending points differ significantly and for the points are always lower than the corresponding ones for PSM. This can be explained by the fact that for QAM bits are unequally protected.
5.3. Convergence Behavior of Coded PSM
For coded modulation, an important issue is the convergence of the iterative demapping and decoding process. Whether an iterative receiver can converge or not is determined by the channel SNR and, more importantly, by the relation between the decoder characteristics and the demapper characteristics. As a commonly used tool, an EXIT chart can elegantly demonstrate the suitability of a channel code for a given signal mapper. By means of an EXIT chart analysis, we will see that there is indeed a strong reason for the good performance of repetitioncoded PSM systems, and we will also see that the requirements of superposition mapping on channel codes are essentially different with respect to conventional mapping schemes.
Let us assume that the SNR per code bit is dB and the bit load is . Given this setup, the MI transfer curve of a PSM demapper is plotted as a dashed dot curve in Figure 8. The MI transfer curves for several decoders are also plotted, with the horizontal and vertical axes swapped. To guarantee convergence, the MI transfer curve of the decoder must be below the MI transfer curve of the demapper, so as to open the tunnel for iterative refining of the soft decisions. Otherwise, the iterative process will get stuck at a certain point and no additional gain is achievable by further iterations.
As one can see from Figure 8, given a regular LDPC code with column weight , one needs to drop the code rate to as low as in order to open the tunnel. The main problem is in the left region. As already explained in Section 5.2, the MI transfer curve of a PSM demapper with large starts from a rather low point but ends at a rather high point. Meanwhile, the MI transfer curve of an LDPC code always possesses a wide quasiflat section, mainly due to the nature of parity checks. This situation makes the tunnel difficult to open in the left region but often unnecessarily wide in the right region, which clearly explains the poor performance of LDPCcoded PSM at large bit loads , as shown in Figure 6. As a matter of fact, the classical strong codes, such as Turbo codes and LDPC codes, purely built upon parity checks, do not fit with PSM very well. To fully exploit the capacityachieving potential of superposition mapping, new codes and new code design concepts are necessary. Nevertheless by checking Figure 7(b) carefully, one recognizes that the MI transfer characteristics of LDPC codes perfectly match with that of QAM, which explains the excellent performance of LDPCcoded QAM systems.
In contrast to paritycheckbased codes, a simple rate repetition code can already effectively open the tunnel for convergence, which can also be validated by the good performance of repetitioncoded PSM in Figure 6. Repetition codes come with zero coding gain, in the sense that lowering the ending point of the MI transfer curve is only possible via an equivalent amount of degradation in the . Nevertheless, due to the special property of PSM, this issue does not present a big problem. For reasonable SNRs, the MI transfer curves of PSM always end at a very high point. Note that, for PSM with large bit loads, the primary task of channel coding is no longer to combat the additive noise but to guarantee the separation of superimposed binary chips. As long as all chips are perfectly separated, the BER performance of PSM will asymptotically approach that of BPSK, while the performance of uncoded BPSK is already very good at dB. Above all, the difficult part is the first few iterations. A decoder has to be able to deliver reliable feedback given very weak inputs in order to let the iterative demapping and decoding go on properly. With respect to this concern, however, a repetition code is the best choice. One may call the checks of a repetition code as equality checks. There is effectively only one info bit involved in each equality check. As a result, the feedback information of an equality check can be as strong as needed at the very beginning of iterative processing, if the coding rate is low enough, illustrated by the MI transfer curve of a rate repetition code in Figure 8. Note that the MI transfer curve of the PSM demapper is often concave, which creates a severe problem for paritycheckbased codes, but this is not a problem for repetition codes, because the curves for repetition codes are also concave for . Therefore, although a pure repetition code cannot be optimal for PSM, it is definitely a good choice among others.
To locate the performance of repetitioncoded PSM, we compare it to several systems with the same bandwidth efficiency in Figure 9. For an information rate of bits per channel symbol, uncoded QAM has a distance of about dB to the Shannon limit, while a rate LDPCcoded QAM system shortens this distance by dB. In comparison, rate repetitioncoded PSM with is in fact just dB away from the Shannon limit, in spite of zero coding gain. Although the codes for both PSM and QAM have not yet been optimized, these results give a rough impression about their relative performance.
6. Alternative Demappers
APP demapping is a good choice for system analysis but the computational complexity is very high. Hence, two alternative demappers are brought out and a brief analysis is given.
6.1. Gaussian Approximation Approach
The Gaussian approximation (GA) is well known from multiuser systems. This concept has been widely used in multipleaccess/multiplexing systems [18, 19]. The main idea is that the interfering superimposed symbols, together with the Gaussian noise are approximated by a single Gaussian random variable. Hence, the LLR of can be obtained via where the mean and variance of the interfering signal are updated by feedback information from the decoder. According to the turbo principle, as the feedback information improves from iteration to iteration, the demapper estimates get more reliable. The complexity increases linearly with the bit load , which makes Gaussian approximation very attractive for practical implementations. However, the approximation is not always good enough and can severely limit the performance. Details on this will be given in Section 6.5.
6.2. TreeBased Approach
In [12], SM is modelled by a tree diagram. Since a tree diagram is a special case of a Markov process, the BahlCockeJelinekRaviv (BCJR) algorithm [20] can be used for SISO demapping of SM to reduce the computational complexity. Let denote the state at the th level. By the property of superposition mapping, the relationship between the states of two neighboring levels is simply given by The a priori distribution of the states is evaluated recursively according to through the tree by propagating the values from root to leaves. The a priori information is given via the branches to the lower level and multiplied with the corresponding chip probability, as illustrated in Figure 10. Now, the extrinsic LLR of the th chip can be obtained via The likelihood of the received value given the state at the th level can be calculated by a backward recursion through the tree. Starting from the leaves, one calculates recursively by adding together the likelihood values from the branches that have been multiplied with the corresponding chip probabilities. This approach cleverly utilizes the probability propagation and hence considerably reduces the computational complexity. However, the complexity is still exponentially increasing. Inspired by the tree structure, we would like to introduce a novel method of how to reduce the size of the tree without big sacrifices concerning the performance.
6.3. Pruned TreeBased Approach
The core idea is based on the fact that if at some level of the tree two nodes are close to each other, then during the subsequent tree expansion the corresponding subtrees will always keep the distance relation. (This means that the superposition values for nodes are similar.) In other words, the two subtrees are the same, just one is a shifted version of the other. In the special case that two nodes have exactly the same superposition value, then the subtrees are identical. Such subtrees are redundant and can be pruned. Figure 10 illustrates one possible merging scenario. Considering the demapping process, nothing is changed. All the bit paths still exist, the only difference compared to the full tree is that all pruned node values are shifted by a certain constant. In order to control the pruning rate (and hence the computational complexity), we introduce a merging threshold and denote it by . Now starting from the root, for every level the squared difference values of all nodes are checked if they fulfil where and denote two node values from that level. If two nodes are in the range of , then is merged to and pruned. With a single merging operation actually constellation point pairs are merged, that differ by , because a node at level , if expanded, would relate to leaves. Hence, the tree is reduced by the given subtree from node to the leaves, resulting in pruned nodes. Once the whole tree is processed, all nodes in the range of are merged and the tree will be stored for permanent use.
However, there are a few problems. First, with multiple mergers, a node may drift quite far from its original value, maximally by if the remained node always gets merged to another node. The second issue comes from detection. After pruning the tree, some constellation points do not exist in the tree anymore. Hence, given a cut symbol is transmitted, an increased SNR will not lead to a better demapping performance, as such signal point does not exist in the tree anymore. To overcome this problem, we should adjust the transmitter to fit to the receiver. Therefore, the same pruned tree should be used to select the transmit symbol, given the coded bits. One takes coded bits and follows the tree from root to leaf, while choosing the branch according to the bit. This way the ambiguity between the mapper and demapper is removed, as both sides are working with the same constellation space.
The parameter gives a certain freedom to balance between complexity and performance. Clearly if one would prune the tree too much, the performance would degrade significantly. From simulations, a certain point was found after that catastrophic merging takes place. This happens if is large enough so that any code bit sequences, “” and “”, for any , get merged. The distance between these two bit sequences is shown in Figure 11 by the dashed line.
Hence, to avoid such short span mergers, should be chosen smaller than . Given the amplitude factor , the boundary values are listed in Table 1. The formula to calculate for a fixed is The node reduction is significant. For already approximately of the tree is pruned and the rate increases with increasing . In the last column, we can see the symbol cardinality corresponding to the pruned tree, . For it is about of . Clearly the mapping is no longer bijective. The new constellation diagram and probability distribution are shown in Figures 13 and 12. As stated before, after pruning is finished, all nodes in the range of are merged. Hence, the central region is no longer geometrically densely populated, as seen in Figure 2, but instead probabilistically nonuniform. Correspondingly, there are many bit sequences merged to constellation points in the central region and less near the border.

(a)
(b)
(c)
(a)
(b)
(c)
6.4. Complexity Comparison
As mentioned before, the Gaussian approximation demapper has a very low complexity that increases linearly with . APP and full treebased demapper both have exponentially increasing complexity, but the latter already shows a noticeable reduction. For APP, to calculate the LLRs for each chip, the demapping algorithm has to go through constellation points, meaning for each symbol it visits points. However, for treebased demapping, due to the tree structure the complexity to calculate the LLR for each chip varies. For the top level one needs to consider just nodes. Totally, considering the forward and backward recursion and the LLR calculation, a treebased demapper visits roughly points. Hence, already the full tree reduces the complexity compared to APP demapping. As can be seen from Table 1, the pruned tree significantly reduces the whole tree size, leading to a proportionally smaller computational complexity.
6.5. Performance
The Gaussian approximationbased demapper has a very low complexity, but it is associated with a severe performance degradation. In Figure 14, the MI transfer characteristics for both pruned tree and GA demapper are shown. Clearly GA does not work so well. In [21] it has been pointed out that for a rate 1/2 repetition code, GA can only support bit loads up to and after that presents a very high error floor. The pruned tree approach (Using values from Table 1) shows much smaller degradation in the MI transfer characteristics with respect to GA. The comparison between the BER performance of pruned tree and GA demapper is given in Figure 15. For , the GA demapper makes a severe problem for convergence. Comparing Figure 15 with Figure 6, we see that tree pruning brings some performance degradation. This is easy to understand, since a certain amount of information is lost during pruning. Nevertheless, tree pruning does not make a big problem for convergence.
7. PAPR Control and Compensation
The output symbols of a superposition mapper inherently exhibit a large peaktoaverage power ratio (PAPR). High peaks occur when the superimposed chips have similar polarities. The PAPR of the output symbols is defined as where denotes the average symbol power (for simplicity, we use in the following). For PSM (), the PAPR value can be calculated as where the first equation comes from the fact that the highest peak happens when the component bits are all zeros or all ones. From (20), it is clear that the PAPR grows linearly with the bit load . Consequently, the power amplifier has to operate with a large backoff, which reduces the power efficiency.
Clipping at the transmitter side is an efficient and simple method to reduce the PAPR. As shown in Figure 16, if the output symbol has a larger magnitude than the given clipping threshold , the clipper (CLP) will limit the magnitude of the symbol while keeping its phase as follows: The clipping process is usually characterized by the clipping ratio (CR) , which is defined as Certainly, the power of clipped symbols decreases with . As shown in [22], the average output power of the clipper is given by The power loss due to clipping can be compensated by subsequent normalization. To preserve the same average power compared to the unclipped symbol, all symbols must be amplified by a factor : As a result, more power is allocated to the unclipped symbols after normalization. This process can be treated as a special form of unequal error protection, which makes the unclipped symbols more robust to the channel noise. The PAPR of the clipped symbol remains the same after normalization since the symbols within the burst are multiplied by the same factor .
With a subsequent pulse shaping filter, there will be no bandwidth expansion for the signal in continuoustime domain. However, new peaks may grow since filtering usually causes overlapping between the consequent symbols.
The distortion due to clipping can be described by a clipping noise . The clipped symbol can be modeled as a summation of the unclipped symbol and the clipping noise as follows: After normalization and for the AWGN channel, the received signal can be written as follows:
7.1. Mutual Information of Clipped PSM
The mutual information of clipped PSM is given in Figure 17, in which the PSM symbols are clipped to have the same PAPR as conventional QAM with the same bit load. Compared to the unclipped PSM in Figure 4(a), the mutual information of clipped PSM does not degrade significantly. Revisiting Figure 4(b), we see that even with the same PAPR, PSM still outperforms QAM in the slope region.
7.2. Clipping Noise Estimation and Compensation
To compensate the distortions introduced by clipping, clipping noise should be estimated and removed from the received signal. Assuming that the clipping threshold and the normalization factor are known at the receiver side, the clipping noise can be estimated, for example, as follows [23]: where denotes the symbol alphabet and is the clipping noise corresponding to symbol .
Equation (27) is optimal in the sense of minimizing the mean square error of the estimated clipping noise. Unfortunately, the computational complexity of this algorithm grows exponentially with bit load . As an alternative algorithm, soft compensation algorithm is proposed by Tong et al. in [24, 25]. The clipping noise is treated as an equivalent Gaussian noise sample, and a lookup table method is used to speed up the detection. Another alternative is the soft reconstruction algorithm (SRA). The idea is to use decoder feedback to reconstruct the soft transmitted symbol then repeat the clipping process as in the transmitter and derive the clipping noise. In the following, we will briefly introduce the SRA algorithm proposed in [26] and extend it to the case of APP demapping.
Let denote the extrinsic LLR of binary chips from the channel decoder, then its corresponding soft binary chip can be calculated as follows: Using the superposition mapping rule, the soft symbol can be obtained by superimposing the binary soft chips with known power and phase allocation as follows: With the knowledge of the reconstructed symbol and the clipping threshold , the estimated clipping noise can be obtained as follows: Then the received signal is refined by subtracting the estimated clipping noise as follows: The refined signal can be used in the APP demapper. Compared to the optimal solution in (27), the proposed SRA method has only a linear complexity.
Figure 18 shows the BER performance for the clipped PSM transmission over the AWGN channel. After clipping, the PAPR of the output symbol is reduced from dB to dB. It can be seen that an error floor exits even at the high SNR region if clipping noise is not compensated. With the SRA algorithm, the SNR loss due to clipping is reduced to dB at . This result demonstrates that the SRA algorithm can efficiently compensate the performance loss due to clipping while introducing only marginal complexity overhead.
8. Conclusions and Future Work
In this paper, we have carried out an extensive study on phaseshifted superposition mapping (PSM), particularly on its behavior in the scenario of iterative demapping and decoding. It is shown that PSM is a quasibijective mapping scheme and provides no rate limit in a coded system. Due to a geometrically Gaussianlike symbol distribution, PSM has a good potential to approach the capacity of Gaussian channels. Analogous to conventional mapping schemes like PSK/QAM, PSM can easily be applied in a bitinterleaved coded modulation (BICM) scenario, albeit with different requirements on the channel code. Via an EXIT chart analysis, it is found that for PSM with large bit loads a simple repetition code can already outperform a classical LDPC code. Though surprising, the reason for this phenomenon is indeed simple. Because of superimposing binary chips with identical power, the main task of the channel code is to guarantee a perfect separation of superimposed chips instead of combating the noise. A repetition code simply works better than a paritycheck code with respect to this purpose. Numerical results show that rate regularrepetitioncoded PSM with bit load can outperform regularLDPCcoded QAM with the same bandwidth efficiency and is indeed just dB away from the Shannon limit at a BER of .
Besides theoretical concerns, several practical issues are also treated in this contribution. Using a tree diagram to represent the constellation evolution process of PSM and pruning those nodes that are close enough to each other, a dramatic complexity reduction can be achieved with an acceptable performance degradation. Furthermore, by baseband clipping at the transmitter side in conjunction with iterative soft compensation at the receiver side, the peaktoaverage power ratio of PSM symbols can be controlled to a reasonable level without much sacrificing the BER performance.
There are at least two interesting topics for future work. A repetition code can give an excellent performance for a PSM system, particularly in the initial iterations. Nevertheless, in latestage iterations paritycheck codes can provide some gain over repetition codes. Therefore, finding good hybrid repetition and paritycheck codes deserves to be an interesting topic for superposition mapping. Second, the good performance of the prunedtreebased SISO demapping algorithm provides an important hint. In the PSM constellation, some points are close to each other and some not. This certainly brings some penalty in case of noisy channels. It is worthwhile to check if one can use a tree to refine the PSM constellation to achieve additional performance improvement.
Acknowledgment
This work has been supported by the German Research Foundation (DFG) under Contracts nos. HO 2226/101 and HO 2226/92.
References
 C. E. Shannon, “A mathematical theory of communication,” Bell System Technical Journal, vol. 27, pp. 379–423, 623–656, 1948. View at: Google Scholar
 T. M. Cover and J. A. Thomas, Elements of Information Theory, John Wiley & Sons, New York, NY, USA, 2nd edition, 2006.
 F. R. Kschischang and S. Pasupathy, “Optimal nonuniform signaling for Gaussian channels,” IEEE Transactions on Information Theory, vol. 39, no. 3, pp. 913–929, 1993. View at: Publisher Site  Google Scholar
 R. F. H. Fischer, Precoding and Signal Shaping for Digital Transmission, John Wiley & Sons, New York, NY, USA, 2002.
 E. Schrödinger, Statistical Thermodynamics, Cambridge University Press, Cambridge, UK, 1962.
 G. D. Forney Jr., “Trellis shaping,” IEEE Transactions on Information Theory, vol. 38, no. 2, pp. 281–300, 1992. View at: Publisher Site  Google Scholar
 G. R. Lang and F. M. Longstaff, “A leech Lattice modem,” IEEE Journal on Selected Areas in Communications, vol. 7, no. 6, pp. 968–973, 1989. View at: Publisher Site  Google Scholar
 P. Fortier, A. Ruiz, and J. M. Cioffi, “Multidimensional signal sets through the shell construction for parallel channels,” IEEE Transactions on Communications, vol. 40, no. 3, pp. 500–512, 1992. View at: Publisher Site  Google Scholar
 D. G. Forney Jr. and G. Ungerboeck, “Modulation and coding for linear Gaussian channels,” IEEE Transactions on Information Theory, vol. 44, no. 6, pp. 2384–2415, 1998. View at: Google Scholar
 L. Duan, B. Rimoldi, and R. Urbanke, “Approaching the AWGN channel capacity without active shaping,” in Proceedings of IEEE International Symposium on Information Theory (ISIT '97), p. 374, Ulm, Germany, June 1997. View at: Google Scholar
 H. Schoeneich and P. A. Hoeher, “Adaptive interleavedivision multiple access—a potential air interface for 4G bearer services and wireless LANs,” in Proceedings of the International Conference on Wireless and Optical Communications and Networks (WOCN '04), Muscat, Oman, June 2004. View at: Google Scholar
 X. Ma and L. Ping, “Coded modulation using superimposed binary codes,” IEEE Transactions on Information Theory, vol. 50, no. 12, pp. 3331–3343, 2004. View at: Publisher Site  Google Scholar
 G. Caire, G. Taricco, and E. Biglieri, “Bitinterleaved coded modulation,” IEEE Transactions on Information Theory, vol. 44, no. 3, pp. 927–946, 1998. View at: Google Scholar
 T. Wo and P. A. Hoeher, “Superposition mapping with application in bitinterleaved coded modulation,” in Proceedings of the International ITG Conference on Source and Channel Coding (SCC '10), Siegen, Germany, January 2010. View at: Google Scholar
 H. Schoeneich, Adaptiver InterleaveDivision Mehrfachzugriff (IDMA) mit Anwendung in der Mobilfunkkommunikation, Ph.D. dissertation, University of Kiel, Kiel, Germany, 2007.
 S. ten Brink, “Convergence of iterative decoding,” Electronics Letters, vol. 35, no. 13, pp. 1117–1118, 1999. View at: Google Scholar
 S. ten Brink, “Convergence behavior of iteratively decoded parallel concatenated codes,” IEEE Transactions on Communications, vol. 49, no. 10, pp. 1727–1737, 2001. View at: Publisher Site  Google Scholar
 L. Ping, L. Liu, and W. K. Leung, “A simple approach to nearoptimal multiuser detection: Interleavedivision multiple access,” in Proceedings of IEEE Wireless Communications and Networking Conference (WCNC '03), pp. 391–396, New Orleans, La, USA, March 2003. View at: Google Scholar
 H. Schoeneich and P. A. Hoeher, “A hybrid multiple access scheme approaching single user performance,” in Proceedings of the Workshop on Signal Processing in Communications (SPC '03), pp. 163–168, Baiona, Spain, September 2003. View at: Google Scholar
 L. R. Bahl, J. Cocke, F. Jelinek, and J. Raviv, “Optimal decoding of linear codes for minimizing symbol error rate,” IEEE Transactions on Information Theory, vol. 20, no. 2, pp. 284–287, 1974. View at: Google Scholar
 M. Noemm, T. Wo, and P. A. Hoeher, “Multilayer APP detection for IDM,” Electronics Letters, vol. 46, no. 1, pp. 96–97, 2010. View at: Publisher Site  Google Scholar
 H. Ochiai and H. Imai, “Performance analysis of deliberately clipped OFDM signals,” IEEE Transactions on Communications, vol. 50, no. 1, pp. 89–101, 2002. View at: Publisher Site  Google Scholar
 S. M. Kay, Fundamentals of Statistical Signal Processing, vol. 1 of Estimation Theory, Prentice Hall, Upper Saddle River, NJ, USA, 1st edition, 1993.
 J. Tong, L. Ping, and X. Ma, “Superposition coding with peakpower limitation,” in Proceedings of the IEEE International Conference on Communications (ICC '06), pp. 1718–1723, Istanbul, Turkey, June 2006. View at: Publisher Site  Google Scholar
 J. Tong, L. Ping, and X. Ma, “Superposition coded modulation with peakpower limitation,” IEEE Transactions on Information Theory, vol. 55, no. 6, pp. 2562–2576, 2009. View at: Publisher Site  Google Scholar
 D. Hao and P. A. Hoeher, “Iterative estimation and cancellation of clipping noise for multilayer IDMA systems,” in Proceedings of the International ITG Conference on Source and Channel Coding (SCC '08), Ulm, Germany, January 2008. View at: Google Scholar
